Product Description

The Villaon V201 Series is a Residual Current Operated Circuit Breaker with Overcurrent Protection (RCBO). It is designed to protect electrical circuits and personnel against earth leakage (electric shock), overload, and short-circuit faults. This device combines the functions of an MCB (Miniature Circuit Breaker) and an RCCB (Residual Current Circuit Breaker) into a single compact unit, making it ideal for residential, commercial, and industrial distribution boards where space is limited but comprehensive safety is required.

Key Features TableFeature CategorySpecification / DescriptionProduct SeriesV201 Series (RCBO)Device TypeResidual Current Circuit Breaker with Overcurrent ProtectionPole Configuration1P+N (Single Pole + Neutral)Rated Current (In​)6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63ARated Voltage (Ue​)230V AC (Single Phase)Rated Frequency50Hz / 60HzRated Residual Current (IΔn​)30mA (Standard for personal protection) / 300mARated Breaking Capacity4.5kA / 6kATripping CharacteristicB Type / C Type / D TypeProtection TypeOverload, Short Circuit, & Earth LeakageLeakage Action TypeInstantaneous (Type AC / Type A)Mounting Type35mm DIN Rail StandardTerminal TypeCombined Box/Angle TerminalsCompliance StandardsIEC 61009-1 / EN 61009-1
