Product Description

The Villaon V45 32+2(3G) is a professional 19-inch Rack-Mount Surge Protective Device (SPD) designed for medium-to-large CCTV and Security Systems. It provides centralized protection for digital video recorders (DVR/NVR) by defending signal and power lines against transient overvoltages. The "32+2" configuration indicates protection for 32 video channels and 2 power lines. The "(3G)" designation ensures the device supports 3G-SDI high-definition broadcast standards, offering high-bandwidth protection with minimal signal loss for critical surveillance infrastructure.

Key Features TableFeature CategorySpecification / DescriptionProduct ModelV45 32+2(3G)Product TypeVideo Signal & Power Surge Protective Device (SPD)Form FactorStandard 19-inch Rack Mount (1U Height)Protection Channels32 Channels (Video Signal) + 2 Channels (Power Supply)Video Compatibility3G-SDI, HD-SDI, SD-SDI, HDMI, and Analog (CVBS)Frequency BandwidthDC ~ 3GHz (Supports High-Definition Signals)Video ConnectorsBNC Female (Input to Output)Power Voltage Rating (Uc​)12V DC / 24V DC / 220V AC (Model Dependent)Max Discharge Current (Imax​)Video: 5kA (8/20μs) / Power: 10kA - 20kA (8/20μs)Voltage Protection Level (Up​)Video: ≤ 600V / Power: ≤ 1.5kVInsertion Loss≤ 0.3dB (Ensures no signal degradation)Response Time≤ 1ns (Nanosecond response speed)Housing MaterialMetallic Rack Chassis (Shielded)ApplicationSecurity Monitoring Systems, Broadcast Studios, Traffic ControlCompliance StandardsIEC 61643-21 / EN 61643-11
