Product Description

The Villaon V45 64+2(3G) is a high-density 19-inch Rack-Mount Surge Protective Device (SPD) engineered for professional CCTV and Security Systems. It serves as a centralized defense unit for video management systems, protecting recording equipment (DVR/NVR) from surge damage. The model designation "64+2" indicates the capacity to protect 64 video channels and 2 power lines, making it ideal for large-scale surveillance installations. The "(3G)" specification ensures compatibility with 3G-SDI high-definition broadcast signals, providing high-bandwidth protection without signal latency or quality loss.

Key Features TableFeature CategorySpecification / DescriptionProduct ModelV45 64+2(3G)Product TypeVideo Signal & Power Surge Protective Device (SPD)Form FactorStandard 19-inch Rack Mount (1U or 2U Height)Protection Channels64 Channels (Video Signal) + 2 Channels (Power Supply)Video Compatibility3G-SDI, HD-SDI, SD-SDI, HDMI, and Analog (CVBS)Frequency BandwidthDC ~ 3GHz (High Definition Support)Video ConnectorsBNC Female (High Density Arrangement)Power Voltage Rating (Uc​)12V DC / 24V DC / 220V AC (Depending on sub-model)Max Discharge Current (Imax​)Video: 5kA (8/20μs) / Power: 10kA~20kA (8/20μs)Clamping Voltage (Up​)Video: ≤ 600V / Power: ≤ 1.5kVInsertion Loss≤ 0.3dB (Maintains signal integrity)Response Time≤ 1ns (Nanosecond-level protection)Housing MaterialAluminum / Steel Rack ChassisApplicationLarge Video Surveillance Systems, Traffic Control, Broadcast StudiosCompliance StandardsIEC 61643-21 / EN 61643-11
